pe 注塑四通
pe plastic injection cross pipe
压力等级：适用于工作压力不大于1.6mpa
pressure grade: suitable for the working pressure not larger than 1.6mpa
规格型号：dn 63mm～dn
355mm
specification and model: dn
63mm～dn 355mm
执行标准：东宏牌pe注塑四通执行国家标准gb/t13663.2-2005与gb 15558.2-2005
executive standards: for pe plastic injection cross pipe of donghong, national standards gb/t13663.2-2005 and gb 15558.2-2005 apply.
规格尺寸：pe注塑四通规格尺寸符合下表要求
specification and dimension: specification and dimension of pe plastic injection cross pipe meet the
requirements in the table below
pe注塑四通规格尺寸
specification and dimension of pe plastic injection
cross pipe
|
产品规格d/mm |
l/mm |
a/mm |
h/mm |
|
63 |
230 |
63 |
115 |
|
90 |
295 |
79 |
147 |
|
110 |
380 |
82 |
190 |
|
160 |
430 |
98 |
215 |
|
200 |
420 |
90 |
210 |
|
250 |
500 |
110 |
250 |
|
315 |
615 |
130 |
307 |
|
355 |
660 |
130 |
330 |
